Current Configurations of ISS for use on HSF web
JSC2010-E-008593 (January 2010) --- Computer-generated artist?s rendering of the International Space Station as of Jan. 23, 2010. Pressurized Mating Adapter 3 (PMA-3) is relocated from the Unity node port to the Harmony node zenith port to allow for the arrival of the Tranquility module (Node 3). Soyuz 20 (TMA-16) is docked to the Poisk Mini-Research Module 2 (MRM2). Soyuz 21 (TMA-17) is linked to the Zarya nadir port and Progress 35 resupply vehicle remains docked to the Pirs Docking Compartment.
