Current Configurations of ISS for use on HSF web
JSC2009-E-147799 (July 2009) --- Computer-generated artist?s rendering of the International Space Station as of July 29, 2009. Progress 34 supply vehicle docks to the Zvezda Service Module?s aft port. Soyuz 18 (TMA-14) remains docked to the Pirs Docking Compartment and Soyuz 19 (TMA-15) remains linked to the Zarya nadir port. During the STS-127 mission, the Japanese Exposed Facility was added to the Japanese Kibo complex.
Usage Rights
Most NASA images are in the public domain and free to use. Credit NASA as the source. Check NASA's media usage guidelines for details. Images featuring identifiable individuals may require additional permissions.
Details
NASA ID
jsc2009e147799
Date Created
July 29, 2009
Center
JSC
Media Type
Downloads
Download this image in multiple resolutions. All NASA media are free for public use.
