Current Configurations of ISS for use on HSF web
JSC2008-E-026785 (March 2008) --- Computer-generated artist's rendering of the International Space Station as of March 23, 2008. The Kibo Japanese Experiment Logistics Module -- Pressurized Section (JLP) is attached to the zenith port of the Harmony node. Dextre, also known as the Special Purpose Dextrous Manipulator (SPDM), is assembled and temporarily attached to the Destiny laboratory grapple fixture. The shuttle's Orbiter Boom Sensor System (OBSS) is stored on the S1 truss. Progress 28 remains docked to the Pirs Docking Compartment and Soyuz 15 (TMA-11) is linked to the Zarya nadir port.
