Current Configurations of ISS for use on HSF web
JSC2006-E-40784 (September 2006) --- Computer-generated artist's rendering of the International Space Station following scheduled activities of Sept. 20, 2006. This angle shows the port side view of the orbiting complex. Soyuz 13 (TMA-9) spacecraft, transporting the Expedition 14 crew, docks to the Zvezda Service Module aft port. Progress 22 resupply vehicle remains docked to the Pirs Docking Compartment and Soyuz 12 (TMA-8) is docked to the Zarya Module nadir port.
Usage Rights
Most NASA images are in the public domain and free to use. Credit NASA as the source. Check NASA's media usage guidelines for details. Images featuring identifiable individuals may require additional permissions.
Details
NASA ID
jsc2006e40784
Date Created
September 1, 2006
Center
JSC
Media Type
Downloads
Download this image in multiple resolutions. All NASA media are free for public use.
