Ingenuity's Upper Swashplate Assembly
The upper swashplate of NASA's Ingenuity Mars Helicopter controls the pitch of the upper rotor blades as they rotate and is critical to stable, controlled flight. The swashplate is driven by three small servo motors. https://photojournal.jpl.nasa.gov/catalog/PIA24812
