KSC-08pd3761
CAPE CANAVERAL, Fla. – Vince Bilardo, project manager from Glenn Research Center, talks to the media about the arrival of the Ares I-X upper stage simulator components behind him in the Vehicle Assembly Building's high bay 4 at NASA's Kennedy Space Center in Florida. The upper stage simulators will be used in the test flight identified as Ares I-X in 2009. The segments will simulate the mass and the outer mold line and will be more than 100 feet of the total vehicle height of 327 feet. The simulator comprises 11 segments that are approximately 18 feet in diameter. Most of the segments will be approximately 10 feet high, ranging in weight from 18,000 to 60,000 pounds, for a total of approximately 450,000 pounds. Photo credit: NASA/Jim Grossmann
Usage Rights
Most NASA images are in the public domain and free to use. Credit NASA as the source. Check NASA's media usage guidelines for details. Images featuring identifiable individuals may require additional permissions.
Details
NASA ID
KSC-08pd3761
Date Created
November 12, 2008
Center
KSC
Media Type
Location
Kennedy Space Center, FL
