STOVL (Short Take Off Vertical Landing) Phase III Hot Gas Ingestion Into Engine Intake Test in the 9x15 Low Speed Wind Tunnel
The 9x15 low speed tunnel tests take off and landing of aircraft. The laser velocimetry system for flow measurement show here, with the color blue and green lasers, measures engine exhaust that comes back up from the ground. The STOVL model n the 9x15 low speed wind tunnel, building 39, is similar to the British Harrier aircraft.
Usage Rights
Most NASA images are in the public domain and free to use. Credit NASA as the source. Check NASA's media usage guidelines for details. Images featuring identifiable individuals may require additional permissions.
Details
NASA ID
GRC-1994-C-00159
Date Created
January 5, 1994
Center
GRC
Media Type
Photographer
NASA/GRC/QUENTIN SCHWINN
Location
NASA Glenn Research Center
