XB-32 model wing with 15% chord sealed gap aileron. Flaps extended to 40 degrees. The first wind-tunnel report published by Ames Covered the XB-32 Test in the 7-by-10 No. ! and was authored by Roy P. Jackson and George L. Smith Jr.
Most NASA images are in the public domain and free to use. Credit NASA as the source. Check NASA's media usage guidelines for details. Images featuring identifiable individuals may require additional permissions.
NASA ID
ARC-1969-AAL-1443
Date Created
September 10, 1941
Center
ARC
Media Type
