GE Fan in Wing VZ-11 VTOL airplane in Ames 40x80 Foot Wind Tunnel.
3/4 front view VZ-11 ground test - variable height struts. Engines of the VZ-11 are a pair of General Electric J85-5 turbojets, mounted in high in the centre fuselage, well away from fan disturbance. Designed in the Ames 40x80 foot wind tunnel.
Usage Rights
Most NASA images are in the public domain and free to use. Credit NASA as the source. Check NASA's media usage guidelines for details. Images featuring identifiable individuals may require additional permissions.
Details
NASA ID
AC-30211
Date Created
December 27, 1962
Center
ARC
Media Type
Photographer
NASA
Location
Ames Research Center
